Formulation Instructions

Formula

Ingredient
Amount
% as is
HOMECRAFT® Pulse CT 1203 Pea Flour
61.5
Pea fiber
7.0
VITESSENCE™ Pulse CT 1552 Pea Protein
7.0
HI-MAIZE® 260 Resistant Starch
21.0
Salt
1.0
Sugar
2.5
TOTAL
100.00

Preparation

1. Dry blend all ingredients.
2. Process well blended dries using twin-screw extruder with 6 barrels and 32 mm screw diameter using the following parameters:

Total Moisture (%) = 20.9

Barrel Zone 1 (°C) = 5

Barrel Zone 2 (°C) = 80

Barrel Zone 3 (°C) = 100

Barrel Zone 4 (°C) = 110

Barrel Zone 5 (°C) = 110

Barrel Zone 6 (°C) = 110

Die Temp (°C) = 118

Screw Speed (rpm) = 397

Cutter Speed (rpm) = 775

Preparation

  1. Dry blend all ingredients.
  2. Process well blended dries using twin-screw extruder with 6 barrels and 32 mm screw diameter using the following parameters:

Total Moisture (%) = 20.9

Barrel Zone 1 (°C) = 5

Barrel Zone 2 (°C) = 80

Barrel Zone 3 (°C) = 100

Barrel Zone 4 (°C) = 110

Barrel Zone 5 (°C) = 110

Barrel Zone 6 (°C) = 110

Die Temp (°C) = 118

Screw Speed (rpm) = 397

Cutter Speed (rpm) = 775
